DIN 34821:2005 Socket Head Cap Internal 12-Point Drive Screw features an internal 12-point drive, offering multiple contact points for precise tool positioning and controlled torque transmission in restricted assembly spaces.
The cylindrical head provides a neat appearance on equipment surfaces, while the internal drive reduces external clearance requirements. The multi-point drive form also helps distribute tool load and reduce localized recess deformation.
This screw is suitable for industrial equipment, special-purpose machinery, aerospace-related components, power transmission assemblies, molds, and demanding fixtures. Material grade, strength class, and surface protection can be selected to balance load capacity with long-term serviceability.

Dimensions unit: inch
|
Thread size d |
M6 |
M8 |
M10 |
M12 |
M14 |
M16 |
||
|
P |
Pitch |
Coarse teeth |
1 |
1.25 |
1.5 |
1.75 |
2 |
2 |
|
Fine Teeth |
- |
- |
- |
1.5 |
1.5 |
1.5 |
||
|
da |
Max. |
6.8 |
9.2 |
11.2 |
13.7 |
15.7 |
17.7 |
|
|
dk |
Max. |
10 |
13 |
16 |
18 |
21 |
24 |
|
|
Min. |
9.78 |
12.73 |
15.73 |
17.73 |
20.67 |
23.67 |
||
|
dw |
Min. |
9.38 |
12.33 |
15.33 |
17.23 |
20.17 |
23.17 |
|
|
h |
Max. |
4.2 |
5.48 |
6.78 |
8.08 |
9.48 |
10.58 |
|
|
k |
Max.=Nominal |
6 |
8 |
10 |
12 |
14 |
16 |
|
|
Min. |
5.7 |
7.64 |
9.64 |
11.57 |
13.57 |
15.57 |
||
|
r |
Min. |
0.25 |
0.4 |
0.4 |
0.6 |
0.6 |
0.6 |
|
|
Slot number |
N8 |
N10 |
N12 |
N14 |
N16 |
N18 |
||
|
C |
7.4 |
9.84 |
11.7 |
13.54 |
15.99 |
17.18 |
||
|
t |
Max. |
3.4 |
4.48 |
5.48 |
6.48 |
7.58 |
8.58 |
|
|
Min. |
3 |
4 |
5 |
6 |
7 |
8 |
||
|
V |
Max. |
0.6 |
0.8 |
1 |
1.2 |
1.4 |
1.6 |
|
|
Thousand pieces of steel weigh ≈kg |
- |
- |
- |
- |
- |
- |
||
