DIN 443:2017 Sealing Push-In Cap Washer is used to close and protect holes, shaft ends, or assembly openings. The push-in structure allows quick installation and can help block dust, debris, or minor splashes from entering the internal area.
It can be used in machinery housings, instruments, bearing ends, stamped parts, and repair plugging positions. Its function is not limited to covering an opening; it can also improve appearance and reduce the risk of interference between exposed edges and personnel or wiring.
Specifications can be selected according to hole diameter, material elasticity, sealing requirement, and appearance need, making it suitable for general protection, temporary closure, and light sealing applications.

Dimensions unit: mm
|
Thread size |
8 |
10 |
12 |
14 |
15 |
16 |
18 |
20 |
22 |
24 |
|
|
d |
|
|
|
|
|
|
|
|
|
|
|
|
d |
Max. |
8.155 |
10.155 |
12.2 |
14.2 |
15.22 |
16.22 |
18.22 |
20.272 |
22.272 |
24.272 |
|
Min. |
8.097 |
10.097 |
12.13 |
14.13 |
15.15 |
16.15 |
18.15 |
20.188 |
22.188 |
24.188 |
|
|
h |
Nominal(js) |
3 |
3 |
4 |
5 |
5 |
5 |
6 |
6 |
7 |
7 |
|
Max. |
3.3 |
3.3 |
4.375 |
5.375 |
5.375 |
5.375 |
6.375 |
6.375 |
7.45 |
7.45 |
|
|
Min. |
2.7 |
2.7 |
3.625 |
4.625 |
4.625 |
4.625 |
5.625 |
5.625 |
6.55 |
6.55 |
|
|
r1 |
20 |
25 |
30 |
35 |
38 |
40 |
45 |
50 |
55 |
60 |
|
|
r2 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1.6 |
1.6 |
|
|
s |
Nominal |
0.75 |
0.75 |
1 |
1 |
1 |
1 |
1 |
1 |
1.6 |
1.6 |
|
Max. |
0.9 |
0.9 |
1.15 |
1.15 |
1.15 |
1.15 |
1.15 |
1.15 |
1.75 |
1.75 |
|
|
Min. |
0.6 |
0.6 |
0.85 |
0.85 |
0.85 |
0.85 |
0.85 |
0.85 |
1.45 |
1.45 |
|
|
Weight per thousand pieces kg |
≈ |
0.72 |
0.97 |
2 |
2.98 |
3.2 |
3.55 |
4.83 |
5.55 |
10.8 |
12.3 |
|
Thread size |
25 |
28 |
30 |
36 |
40 |
42 |
45 |
50 |
56 |
63 |
|
|
d |
|
|
|
|
|
|
|
|
|
|
|
|
d |
Max. |
25.302 |
28.302 |
30.302 |
36.374 |
40.374 |
42.425 |
45.425 |
50.425 |
56.525 |
63.525 |
|
Min. |
25.218 |
28.218 |
30.218 |
36.274 |
40.274 |
42.325 |
45.325 |
50.325 |
56.405 |
63.405 |
|
|
h |
Nominal(js) |
8 |
9 |
9 |
11 |
12 |
13 |
14 |
15 |
17 |
19 |
|
Max. |
8.45 |
9.45 |
9.45 |
11.55 |
12.55 |
13.55 |
14.55 |
15.55 |
17.55 |
19.65 |
|
|
Min. |
7.55 |
8.55 |
8.55 |
10.45 |
11.45 |
12.45 |
13.45 |
14.45 |
16.45 |
18.35 |
|
|
r1 |
60 |
70 |
75 |
90 |
100 |
105 |
110 |
125 |
140 |
160 |
|
|
r2 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
2.5 |
2.5 |
|
|
s |
Nominal |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
2 |
2 |
|
Max. |
1.75 |
1.75 |
1.75 |
1.75 |
1.75 |
1.75 |
1.75 |
1.75 |
2.15 |
2.15 |
|
|
Min. |
1.45 |
1.45 |
1.45 |
1.45 |
1.45 |
1.45 |
1.45 |
1.45 |
1.85 |
1.85 |
|
|
Weight per thousand pieces kg |
≈ |
14.3 |
18.2 |
20 |
29.9 |
36.7 |
41.7 |
48.3 |
58.6 |
91.2 |
116 |
① Material:
a) Steel DC03 according to DIN EN 10130, DIN EN 10139; strength grade (material): selected by the manufacturer
b) Other materials according to the agreement.
c) Other intensity levels or specific intensity attributes according to agreement
