ASME/ANSI B18.3:2003 Hex Socket Cone Point Set Screw follows the U.S. dimensional system and is suitable for export equipment, North American projects, and machinery requiring standardized replacement parts. Its cone point provides strong positioning and loosening resistance.
The hex socket allows controlled torque application in compact spaces. When the cone point engages the mating surface or a locating hole, it improves relative position retention between components and helps reduce micro-movement during operation.
This product is used in transmission mechanisms, rotating parts, adjustment devices, fixtures, and general industrial equipment. High-strength alloy steel or corrosion-resistant stainless steel versions can be supplied, with black oxide, zinc plating, or other surface treatments as required.

Dimensions unit: inch
|
Thread size d |
0# |
1# |
2# |
3# |
4# |
5# |
6# |
8# |
10# |
|
|
d |
Thread diameter |
0.0600 |
0.0730 |
0.0860 |
0.0990 |
0.1120 |
0.1250 |
0.1380 |
0.1640 |
0.1900 |
|
PP |
Coarse Thread/UNC |
- |
64.0 |
56.0 |
48.0 |
40.0 |
40.0 |
32.0 |
32.0 |
24.0 |
|
Fine Thread/UNF |
80.0 |
72.0 |
64.0 |
56.0 |
48.0 |
44.0 |
40.0 |
36.0 |
32.0 |
|
|
Extra-Fine Thread/UNEF |
- |
- |
- |
- |
- |
- |
- |
- |
- |
|
|
A |
Nominal quantity |
4 |
4 |
4\6 |
4\6 |
6 |
4\6 |
6\4 |
6 |
6 |
|
Nominal size |
0.033 |
0.033 |
0.048 |
0.048 |
0.060 |
0.069\0.072 |
0.072\0.076 |
0.096 |
0.111 |
|
|
t |
Min. |
0.026 |
0.035 |
0.040 |
0.040 |
0.045 |
0.055 |
0.055 |
0.080 |
0.080 |
|
L |
Nominal |
0.13 |
0.19 |
0.19 |
0.19 |
0.19 |
0.19 |
0.25 |
0.25 |
0.25 |
|
α |
Nominal |
90° |
90° |
90° |
90° |
90° |
90° |
90° |
90° |
90° |
|
Thread size d |
1/4 |
5/16 |
3/8 |
7/16 |
1/2 |
5/8 |
3/4 |
7/8 |
|
|
d |
Thread diameter |
0.2500 |
0.3125 |
0.3750 |
0.4375 |
0.5000 |
0.6250 |
0.7500 |
0.8750 |
|
PP |
Coarse Thread/UNC |
20.0 |
18.0 |
16.0 |
14.0 |
13.0 |
11.0 |
10.0 |
9.0 |
|
Fine Thread/UNF |
28.0 |
24.0 |
24.0 |
20.0 |
20.0 |
18.0 |
16.0 |
14.0 |
|
|
Extra-Fine Thread/UNEF |
32.0 |
32.0 |
32.0 |
28.0 |
28.0 |
24.0 |
20.0 |
20.0 |
|
|
A |
Nominal quantity |
6 |
6 |
6 |
6 |
6 |
6 |
6 |
6 |
|
Nominal size |
0.145 |
0.183 |
0.216 |
0.251 |
0.291 |
0.372 |
0.454 |
0.595 |
|
|
t |
Min. |
0.125 |
0.156 |
0.188 |
0.219 |
0.250 |
0.312 |
0.375 |
0.500 |
|
L |
Nominal |
0.31 |
0.44 |
0.44 |
0.63 |
0.63 |
0.88 |
1.00 |
1.25 |
|
α |
Nominal |
90° |
90° |
90° |
90° |
90° |
90° |
90° |
90° |
FAQ
A: We take every inquiry seriously. On working days, we will respond within 12 hours after receiving your inquiry.
A: We focus on the production of fasteners made of carbon steel, stainless steel, and low-alloy steel. We are a direct manufacturer with independent production capacity. ASME/ANSI B18.3:2003 Hex Socket Cone Point Set Screw Factory. We own several fastener manufacturing facilities and have an international sales department, providing full-process services from production to export.
A: Customized production is our core business. We can develop and manufacture products based on the drawings or samples you provide.
A: Yes. In addition to custom products, we also produce general construction machinery parts (GET parts) for equipment such as excavators, including bucket teeth, tooth holders, corner blades, pins, clips, bolts and nuts. ASME/ANSI B18.3:2003 Hex Socket Cone Point Set Screw Wholesale.
A: We have 12 energy-efficient and environmentally friendly modern production lines (including one fully automatic shell molding line and four heat treatment lines), with an annual production capacity exceeding 20,000 tons, enabling us to steadily meet various order requirements.
A: Trade terms (such as FOB, CIF, etc.) are confirmed when quoting. For batch production, we typically require a 30% deposit, with the balance paid against the copy of the bill of lading. T/T is the main payment method accepted, and L/C can also be negotiated.
A: We are only 35 km away from Shanghai Port and Ningbo Port, so sea freight is the main mode of transportation, which is convenient and efficient. For urgent deliveries, we can also arrange air freight via Ningbo or Shanghai airports.
