ASME/ANSI B18.6.3 (T22):2010 Oval Fillister Head Phillips Screw

ASME/ANSI B18.6.3 (T22):2010 Oval Fillister Head Phillips Screw combines a Phillips drive with a oval fillister head, making it suitable for fastening points that require reliable clamping, removable maintenance, and standardized assembly. The ASME/ANSI framework suits U.S.-standard projects, export equipment, and cross-regional supply chains, supporting smooth alignment between engineering drawings, purchasing lists, and quality inspection.

From an assembly perspective, the cross recess provides good centering and suits production assembly, workstation operations, and joints requiring controlled driving. At the same time, combines a cylindrical head with a rounded top, retaining deeper recess space while offering a smoother exposed profile, so the screw can provide stable fastening performance across different sheet thicknesses, appearance requirements, and space limitations.

It suits instrument components, precision equipment housings, and applications balancing driving stability with appearance. Supply configuration can be refined by size range, strength grade, thread specification, recess control, and surface finish, making it suitable for use with washers, nuts, or pre-tapped holes.

Contact Us

Unit: inch

Thread size d

dk

k

Slot number

M

max

min

max

min

#3

0.161

0.145

0.095

0.077

1

0.105

#4

0.183

0.166

0.107

0.088

1

0.115

#5

0.205

0.187

0.12

0.1

2

0.136

#6

0.226

0.208

0.132

0.111

2

0.159

#8

0.27

0.25

0.156

0.133

2

0.175

#10

0.313

0.292

0.18

0.156

2

0.192

1/4

0.414

0.389

0.237

0.207

3

0.274

5/16

0.518

0.49

0.295

0.262

3

0.315

3/8

0.622

0.59

0.355

0.315

4

0.382
